Product Description
Slotted angle shelving is widely used in daily life nowadays for storage all around the world, especially in the Middle East. It is very easy and simple to assemble, and slotted angle shelving is a kind of ideal shelving for storing files, stationery and small parts.
Slotted Angle provides simple, cost-efficient solutions for virtually any storage requirement. The unique pre-punched hole pattern allows multiple steel sections to be bolted together to form sturdy shelving and storage systems.
The Loading Capacity Varies From Light To Heavy Duty. It Could Be Extended In Width And Height, It Requires No Special Tools, Makes Aceally Slotted Angle System Ideal For Manual Warehousing.
The steel slotted angle shelving is designed various sizes, offering numerous combinations to provide storage solutions for all environments. slotted angle helps you build an efficient framing system for a variety of uses from machine guards to handrails.
Slotted angle is the most versatile, time and cost effective construction material available for building carts, ladders, benches, shelving, cases, racks or any other type of structure. The angle shelving is made of either 12 or 14 gauge roll-formed steel. Slotted angle is finished in grey powder coat enamel or corrosion-resistant galvanized finish.
Slotted Angle Shelving Accessories:
Gusset plates: galvanized steel corner plates give added rigidity and strength, and 14 gauges cold rolled steel measures 6”*6”, The specifications of bolts and nuts is M8*16
Features & Advantages:
Slotted angle shelving basic information:
- Material :High grad of cold rolled steel
- Finish: deoiling –phosphating –plastic spraying
- Loading capability: 80-150kg/layer
- 3,4,5,6 layers is available, and the layer height could be adjustable by free.
- Different dimension, weight capability are available for us widely used in electrical,medicine,supermarket
Slotted angle shelving advantages:
- Cut-in composite beam structure, easy to install and disassemble
- Height of each layer can be adjusted freely for convenient storage
- Load capacity usually between 80-150kg per level
- Connection of main and subsidiary frames for saving space and costs
- Enables efficient storage of a wide range of goods
- It can be used single or connected one by one freely
Ps: Light duty slotted angle shelving non-standard specifications available, if you have special requirements, pls contact me, it can be design as per your needs.
Product Specifications:
| Product name | SPEC (mm) | Thickness (mm) | Length | Capacity (lbs) | Picture |
| Angle post (Equilateral) | 35*35 36*36 37*37 38*38 40*40 | 1.5-2.0 | H24”-144” | 1000-3000 |  |
| Angle post (Inequilateral) | 60*40 57*37 | 1.5-2.0 | H60”-192” | 1500-3500 | |
| Shelves (without supporter) | 900*300/400/450/600 | 0.7-1.0 | 100-200 | ||
| Shelves (with supporter) | 900*300/400/450/600 | 0.7-1.0 | 150-350 | ||
| Corner plate | 70*70 | 0.7 | |||
| Bolts &nuts | M8*16 | ||||
| Base plate |
All of our products can be customized, so don’t hesitate to tell us if the specifications above can not meet your requirements.
